Download Citation. Overvoltage is a failure process initiated by the excessive power supply transient or electrostatic discharge. If overvoltage occurs on the gate, it initiates oxide voltage.

Oxide wearout is a failure process initiated by stressed gate oxides. The circuit fails because the transistors become too slow, and mismatches too large. Oxide wearout includes hot carriers, negative bias temperature instability, and time-dependent dielectric breakdown. Interconnect wearout is a failure process initiated by high currents flowing through the wires.

For wires carrying DC currents the main reason of failure is electromigration, for wires carrying AC currents it is self-heating. Previous Post. Historically, system designers would use a single heat source to model the behavior of a chip within a system. However, understanding spatial thermal characteristics of the IC in a mobile chassis is critical to the success of the passive cooling scheme.

Design reliability

System-centric platforms such as IcePak from Ansys provide the capability for system level thermal analysis on the board and chassis. IC-centric platforms such as Sentinel-TI from Ansys provide the capability to analyze the thermal behavior of the IC within the context of the package boundary constraints.
